Digital Vortex Flow Meter

Digital Vortex Flow Meter

Origin: China

Type: Vortex

Monitor: Remote Type

Size: DN: 25~ 300 mm

Max. Temp: (-25~250) deg C

Max. Pressure: 1.6 Mpa (16 bar)

Accuracy: 1.5%

Body Material: SS

Single Output:4~20 mA, Rs485

Power Supply: 24V DC

Key Features and Benefits of Digital Vortex Flow Meter:

• High Accuracy: Provides precise measurement of water flow rates.
• Non-Invasive Measurement: No moving parts or obstructions in the flow path, minimizing pressure loss and reducing maintenance.
• Wide Flow Range: Can measure a wide range of flow rates, from low to high.
• Remote Monitoring: Many models offer remote monitoring capabilities for convenient data access.
• Pulse Output: Enables integration with other systems for data logging and control.
• Durable Construction: Built to withstand harsh conditions and provide long-lasting performance.
• Low Maintenance: Requires minimal maintenance, reducing operational costs.
• Versatile Applications: Suitable for various applications, including water supply, irrigation, and industrial processes.

How it Works:

1.       Vortex Shedding: As fluid flows past a bluff body (such as a cylinder or wedge) within the flowmeter, vortices are shed alternately from the sides of the body.

2.       Frequency Measurement: The frequency of these vortices is directly proportional to the flow velocity.

3.       Signal Processing: The flowmeter's sensor detects the vortex shedding frequency and converts it into a digital signal.

4.       Flow Rate Calculation: The flow rate is calculated based on the measured frequency and the known pipe diameter.

5.       Digital Display: The calculated flow rate is displayed on the digital screen.

Common Applications:

• Water Supply Systems: For monitoring water consumption in residential and commercial buildings.
• Irrigation Systems: For optimizing water usage in agriculture and landscaping.
• Industrial Processes: For measuring water flow in various industrial processes, such as cooling systems and chemical processing.
• Water Treatment Plants: For monitoring water flow and treatment processes.

Key Considerations When Selecting a Digital Vortex Flow Meter:

• Fluid Properties: Ensure the fluid being measured has sufficient density and viscosity for vortex shedding.
• Pipe Size: Select a meter with a suitable pipe size to ensure accurate measurement.
• Flow Rate Range: Choose a meter with a suitable flow rate range for your application.
• Accuracy Requirements: Consider the desired level of accuracy for your application.
• Environmental Conditions: Assess the operating environment, such as temperature and pressure.
• Installation Considerations: Evaluate the ease of installation and maintenance.
• Cost: Balance the cost of the meter with its features and performance.
